Pipe Line Magnetic Separator
Pipe Line Magnetic Separator
Product Code : MP 17
Brand Name : VIBROMAG
We are known as a prominent name involved in providing a high quality range of Pipe Line Magnetic Separator. This separator is designed for high or low density large volume liquid or semi liquid line flow system. The offered range is manufactured as per the latest market trends using high grade raw materials under the guidance of our professionals. This Pipe Line Magnetic Separator is available in numerous specifications in order to fulfill the variegated needs of the clients. The entire range is appreciated for its compact design, optimum strength and durability.
Pipeline magnetic grate separator is intended to disperse magnetic iron corruption from liquids or dry products of good bulk features. The elementary rudiments the magnetic grate separator in covering comprises of are magnetic tubes (manufactured from stainless steel). Though the substance flows over the magnetic tubes, an actual sturdy magnetic turf (made using the neodymium NdFeB magnets inner of the tubes) traps all metallic rudiments on the external of the tubes. The cliques of tubes are positioned one overhead the other interior of the covering (or one behindhand the other – in case of an upright location of the tubes) and the primary set of tubes comprising one tube fewer. The grate sieve - shaped in this way – is in a very exhaustive interaction with the sinuous material, can seizure even the minutest ferromagnetic froths and promises a tremendously high separation efficacy. The metal elements taken on the magnetic tubes travel to the last of the tubes where they endure endangered from wash-off till the tubes are cleaned.
Throughout manual cleaning the internal portion of the separator is taken out, the magnetic centers are pulled out of the tubes (through operating lever) and the taken magnetic scums fall off the tubes impulsively. In case of better pipeline magnetic separators (if the gutted substance is significantly dirty with ferromagnetic scums), the demagnetization procedure is approved out pneumatically (with involuntary control).
To ensure a rapid and convenient assembly to the pipeline, the separator cover is standardly factory-made in widths from 50 to 250 mm (but we can regulate the joining type as well as its dimension to client's supplies). Our pipeline magnetic separator is convenient to fix and sustain, manufactured from stainless steel and its vigorous design (about very strong neo magnets from rare earth ores) delivers for a long-term and tough solution to parting problems.
Other compensations of magnetic separator for pressure pipeline conveyance MSP-MC:
1) A peephole (made for optical examination of the magnetic tubes and also of the substance flow)
2) A combined lock of the magnetic tubes (stopping unlawful persons from interfering with the separator)
3) A chambered system safeguarding the explosion of the liquid to tremendously strong magnetic field for determined time (the best possible competence of the magnetic separation is attained as the whole length of the magnetic tubes is used)
4) A mesh strainer (eliminating non-magnetic elements)
5) Pipeline magnetic separator discovers utilize in food, ceramic and chemical industries as well as in sanitary amenities.
1) This device employs a number of permanent magnetic stainless steel rods inside the housing.
2) The function of the magnetic rod is to capture the tramp metal particles.
3) It has a top access bolt on steel plate and a rubber seal to remove the magnet cage for cleaning and reinstalled.
